HYDROCLEANER

HYDROCLEANER

HYDROCLEANER

The tipping hydrocleaner to get rid of of the most concentrated sediments!

Specifications

Capacities (l)

from 6000 to 8400

Axle(s)

Single axle

Range

Hydrocleaners

810
HYDROCLEANER General Points

General Points

The Joskin hydrocleaners have been designed for cleaning gullies and sewers or any other work, such as emptying septic tanks, unclogging pipes or vacuuming sediments and waste. They are available in 6,000 and 8,400 l, and are equipped as standard with a Ø4" balanced dorsal boom for an easy handling, a high-pressure clean water injection nozzle for stirring up foreign bodies for easy suction using a high-performance suction technology. The tank of the hydrocleaner can tip and the rear wall can fully open in order to evacuate all the deposits in the tank without any effort.

Specifications

816
HYDROCLEANER Monocoque Tank on Universal Chassis

Monocoque Tank on Universal Chassis

JOSKIN hydrocleaners are equipped with a so-called "universal" chassis on which all stresses are concentrated. It is designed on the basis of the experience gained by JOSKIN in the manufacture of slurry tankers and tipping trailers. Thus, the chassis not only serves as a load-bearing structure for the tank, but also houses the telescopic tipping cylinder on a double oscillating frame (anti-torsion effect). The tank of the hydrocleaners has a robust and lightweight design with a low centre of gravity for an excellent weight/maneuverability ratio. The bodies are made of 5 mm thick hot-dip galvanised high tensile steel and comply with the EN707 safety standard (anti-pitching). The bodies have a monocoque structure and consists of different compartments inside depending on the model and volume of the tanker. In fact, the H6000 hydrocleaner has a compartment of 2,000 l of fresh water for 4,000 l of mud, while the H8400 model offers 2,500 l of fresh water for 5,900 l of mud. Galvanised brackets and belts reinforce the structure of the tipping tank. As standard, the tanks of the hydrocleaners are equipped with a rear hydraulic lever control for opening the rear wall and tipping the tank (ideal for quickly removing residues and sediments, such as stones, sand, etc.).

817
HYDROCLEANER Pumping System

Pumping System

As standard, the hydrocleaners are already equipped with an industrial pumping system consisting of a JUROP DL 180 vacuum pump with a capacity of 18,000 l/min with silencer and air cooling, as well as a high-pressure pump with a capacity of 120 l/min at 120 bar, protected by a water filter. This pump combination has a very low-maintenance and requires no continuous lubrication.

818
HYDROCLEANER Filling Dorsal Boom

Filling Dorsal Boom

The hydrocleaners are also standard fitted with a manual Ø 4'' balanced dorsal boom. At the end of the boom, the operator can manually activate a water injection to facilitate the suction or cleaning of the drain, making the work easy and fast.

819
HYDROCLEANER High-Pressure Circuit/Reel

High-Pressure Circuit/Reel

The high-pressure circuit is mechanically driven, a pressure of 120 bar and a flow rate of 120 l/min allowing the unclogging of sewers with a diameter of 300/400 mm. The manual or hydraulic reel (optional) equipped with a 50 m 3/4'' hose and a rat ensures the unclogging of the pipes. The pressure and water flow rate can be adapted according to the size of the sewer. A lance with a 10-m hose allows you to carry out essential cleaning work around the tank or during the unclogging work.

820
HYDROCLEANER Options

Options

Several options are available to adapt the machine to your future work: a hydraulic dorsal boom, a liquid-ring pump, hydraulic rear wall locks instead of manual ones, a 100 mm diameter gooseneck, a lighting bar with control box, an acoustic warning for the high-pressure water level, red/white stripes on the rear wall (sticker), a remote control, and many more!

Special Features

Pictures

Pictures HYDROCLEANER 1
Pictures HYDROCLEANER 2
Pictures HYDROCLEANER 3
Pictures HYDROCLEANER 4
Pictures HYDROCLEANER 5
Pictures HYDROCLEANER 6
Pictures HYDROCLEANER 7
Pictures HYDROCLEANER 8
Pictures HYDROCLEANER 9
Pictures HYDROCLEANER 10
