CARGO-LIFT CL

CARGO-LIFT CL

Versatile and easy: Cargo-LIFT CL

CARGO-LIFT CL

Specifications

Technical payload (t)

from 10 to 30

Axle(s)

Double axle
Triple axle

Range

Hook-Lift Systems

CARGO-LIFT CL General Points

General Points

The JOSKIN hook-lift system is designed for users who are looking for a professional solution at an affordable price. Either on the road, as a transport vehicle, or in the field, the Cargo-Lift CL is the ideal hook-lift system to meet all your requirements. Available with a double or triple axle and a pullout force of the hook from 8 to 30 t, it is the ideal machine for your containers and implements on a platform from 3 m to 7.45 m.

Specifications

CARGO-LIFT CL Hook-Lift System

Hook-Lift System

The CL models are fitted with a system with a telescopic front arm (except on 8 t where the arm is articulated) with a bolted hook in non-deforming steel (height of the hook: from 1,410 to 1,570 mm). This telescopic system allows to reach a higher tipping angle (44° - 54°) to load a higher number of containers of various lengths. The containers are locked by means of powerful hydraulic hooks, working from the inside to the outside.

CARGO-LIFT CL Arm with Double Hydraulic Ram

Arm with Double Hydraulic Ram

The arm, which is integrated in the structure of the chassis, has a double hydraulic ram (except on 8 t). This structure provides a high stability to the arm as well as a higher movement speed.

CARGO-LIFT CL Quick and Easy Use

Quick and Easy Use

The hydropneumatic drawbar and a tipping assistance hydraulic ram are part of the standard equipment on the D18-D22-T22-T30 models and are available as an option on smaller models. They make the loading of containers easier and quicker. Furthermore, a fast unloading system for empty containers (Eilgang) is also available as an option. A double-acting hydraulic quick coupling can also be added at the back of the Cargo-LIFT to control, for instance, the hydraulic door of a container.

CARGO-LIFT CL Drawbar

Drawbar

For optimal ergonomics of the machine, this hook-lift system is fitted with an “arrow-shaped” drawbar. The very thin design of this drawbar ensures higher steering angles and an outstanding maneuverability.

CARGO-LIFT CL Safety

Safety

Hydraulic safety device on all hook movements in order to avoid operating errors.

Special Features

Discover our super-equipped CARGO-LIFT CL Series at a very attractive price

Discover
Advantage
Pictures cargo-lift cl 1
Pictures cargo-lift cl 2
Pictures cargo-lift cl 3
Pictures cargo-lift cl 4
Pictures cargo-lift cl 5
Pictures cargo-lift cl 6
Pictures cargo-lift cl 7
Pictures cargo-lift cl 8
Pictures cargo-lift cl 9
Pictures cargo-lift cl 10
Pictures cargo-lift cl 11
Pictures cargo-lift cl 12
Pictures cargo-lift cl 13
Pictures cargo-lift cl 14
Pictures cargo-lift cl 15
Pictures cargo-lift cl 16
