TETRA-CAP

TETRA-CAP

A hermetic, universal and manoeuvrable trailer

Specifications

Payload (t)

8 → 16

Axle(s)

Double axle

Range

Tipping Trailers with Drop Sides

768
TETRA-CAP General points

General points

Tetra-CAP are double axle trolley trailers that are ideal for transporting your seed crops (and many other products). They are all made of high tensile steel. The chassis has an ergonomic and durable design thanks to its hot-dip galvanisation (JOSKIN Group's galvanisation plant). The bodies are compact, robust and modular. The 3-sided tipping, as standard, makes them even more versatile. In short: a real multi-talent in transport!

Specifications

570
TETRA-CAP Ease of use

Ease of use

The chassis of the Tetra-CAP is mounted on a parabolic leave running gear. It guarantees flexibility and high operating comfort, both in the field and on the road, even under the most difficult conditions. In extreme applications, rubber suspension buffers also limit leaves crushing, while maintaining soft and smooth machine suspension. A lowered chassis provides a lower centre of gravity, which results in better machine stability and increased driving comfort, both on the road and in the field. In addition, the lowered body makes loading easier. The narrow chassis allows the use of wide wheels to maximise stability. Operating comfort is also improved by the positioning of the axles, which is not left to chance. Indeed, the advanced position of the 1st axle (on turret) offers unprecedented manoeuvrability.

595
TETRA-CAP Galvanised chassis and drawbar

Galvanised chassis and drawbar

In addition to the qualities of the steel and 2K paint used to ensure exceptional durability, the drawbar and chassis are hot-dip galvanised, which provides the best possible protection against corrosion. This is because zinc penetrates the surface of the metal, making it immune to scratches and rust. For easier hitching, return springs (also galvanised) keep the drawbar at hitching height.

596
TETRA-CAP 3-sided tipping

3-sided tipping

In certain areas that are difficult to access or for precise tipping, it can be very useful to be able to tip on the sides of the trailer. This is for example the case if you have to tip in longitudinal chutes or pits, or when the height of the building in which you are unloading does not allow you to tip backwards. In this case, the "3-side" function, standard on all Tetra-CAP models, allows you to tip to the rear (50°) as well as to the left (45°) or right (45°). In this case, the tipping cylinder is attached to an oscillating frame and the lateral tipping angle is automatically limited (limit cable). With a "train of tippers", 3-sided tipping is therefore the essential functionality. All Tetra-CAP trailers are equipped as standard with all the necessary equipment to couple several tippers one behind the other.

572
TETRA-CAP A multi-functional body

A multi-functional body

The body offers many advantages: 3-sided tipping as standard, sides that can be completely or partially dismantled according to the needs of the moment, but also many possible combinations of sides (50 cm, 60 cm or 80 cm) allowing volumes of up to 31.80 m³ to be achieved. By removing all the sides, the trailer can be used as a tray for transporting round bales, square bales or pallets. It can also be equipped with perforated extensions for the transport of silage, hay or green waste. It is also possible to fit a rear grain auger driven by a hydraulic motor. In short: a real multi-use trailer.

573
TETRA-CAP A robust and watertight body

A robust and watertight body

The body is mass-produced from special high tensile steel, identical to that used in the manufacture of road transport vehicles. It is the best guarantee of strength for a relatively low weight. In addition, its closed tube structure increases the resistance of the walls to pressure and provides a smooth line and a modern look to the machine. Another proof of the body's robustness is its bottom made of 4 mm thick high tensile steel, which provides ideal strength without increasing the empty weight. The body is also equipped all around with very high-strength synthetic rubber seals (industrial quality). This ensures a perfect seal and prevents even the smallest seeds and free-flowing products, such as rapeseed, from leaking out. The side panels are locked in place with a large number of hooks that increase the contact between the side panel and the floor seal. Even for journeys on the most bumpy roads, the body provides a perfect seal.
