TRANS-PALM

TRANS-PALM

Monocoque agricultural tipping trailer with low loading height

Specifications

Payload (t)

10 → 16

Axle(s)

Single axle
Double axle

Range

Monocoque Tipping Trailers

765
TRANS-PALM General Points

General Points

The Trans-PALM are monocoque agricultural tipping trailers specialised in the transport of goods loaded by mini-loaders, or by hand. Their low body height ensures an easy loading, whatever the type of implement used. Available with a double axle (from 10 to 12 t technically permissible payload) or a double axle (from 12 to 16 t technically permissible payload), they have a capacity from 6.60 m³ DIN to 16.80 m³ DIN. As an option, 25-cm aluminium extensions significantly increase the capacity. The Trans-PALM monocoque tipping trailers can have side walls of 65 cm or 125 cm high. Nothing is easier than to load this tipping trailer!

Specifications

886
TRANS-PALM Design/Chassis

Design/Chassis

The chassis of the Trans-PALM tipping trailers is 900 mm wide and can therefore be fitted with wide wheels. It is made of profiles tubes of 250 x 100 x 6 mm on models from 4500 to 5000, of 300 x 100 x 6 mm on 5500 and of 300 x 100 x 8 mm on 6000. The Trans-PALM is fitted with a “Y-shaped” open drawbar that, given its structure, provides a very good weight/resistance ratio. Furthermore, its wide fixing points (same width as the chassis) further improve the maneuverability. This solution offers a straight pull/push line and a large vertical clearance at the eyelet and thereby also absorbing shocks. Please note that the drawbar has a cross-suspension ensuring the driving comfort of the whole carriage. The “Y-shaped” drawbar provides a natural traction line and increases the stability of the tipping trailer. This Y shape requires less power, and is therefore more economical and ecological.

887
TRANS-PALM Tapered, Light and Strong Body

Tapered, Light and Strong Body

The bodies of the Trans-PALM tipping trailers are made of a floor sheet and two side sheets in high tensile steel of 4 mm thick. The upper strip is reinforced to resist any accidental impact during loading and to guarantee the rigidity of the body, even with heavier loads. The Trans-PALM bodies are available in 2 standard heights: 65 cm and 125 cm. As an option, they can be fitted with 25-cm aluminium extensions. The manufacturing process of these tipping trailers not only guarantees top quality, but also ensures that the body is perfectly tapered. All Trans-PALM bodies are indeed 8 cm wider at the back in relation to the front, thus ensuring a complete and fluid emptying. The Trans-PALM bodies with 125 cm-high side walls are standard fitted with 4 large sight windows of 21 x 38 cm, so you always have a good view over the load! At the back, they are fitted with a spout over the entire body width.

888
TRANS-PALM Safe Tipping

Safe Tipping

The telescopic hydraulic tipping ram is assembled on a double oscillating frame fitted with greased bearings and integrated in the chassis in a forward position. This system compensates the torsions due to the tipping strains and effectively protects the hydraulic ram and the body from distortions. The advanced position of the hydraulic ram also makes it quicker and easier to tip heavy loads. The back- and and upward position of the tipping hinges increases the unloading height. The standard safety valve, which is directly placed on the hydraulic tipping ram, prevents the body from unexpectedly falling down (e.g. when a hydraulic hose breaks). The first two elements of the hydraulic tipping ram are as a standard chromed. This anti-rust protection allows the body of the tipping trailer to be left tilted backwards, especially during the resting time on a harvesting site, without the risk of rust pitting. As an option, it is possible to add a P.T.O.-shaft driven hydraulic tipping pump with or without lowering control.

889
TRANS-PALM Running Gear

Running Gear

All Trans-PALM tipping trailers are fitted with a movable bolted running gear. This feature is particularly interesting because it allows to modify the weight on the eyelet, and thus on the back side of the tractor, especially when changing the tyres or the drawbar height. The Trans-PALM 4500 et 5000 are single-axle tipping trailers with bolted axle brackets. The models from 5000 to 6000 are standard fitted with a Roll-Over bogie with bolted table (clearance up to 24 cm). This running gear is equipped with parabolic leaves and is characterised by its large ground clearance, which is ideal for works on the fields as well as for a good driving comfort.

890
TRANS-PALM Even More Versatile

Even More Versatile

All JOSKIN Trans-PALM tipping trailers are standard equipped with various pieces of pre-equipment to easily add various options, either at the time of the order or later (even years after the purchase). Among the most interesting options, you can find: aluminium extensions, a tipping pump, plus many more!
